NEW / Open Box ~ Leeson C42T17FZ34A / 096065.00 Gearmotor

NEW / Open Box ~ Leeson C42T17FZ34A / 096065.00 Gearmotor

Regular price $499.00 USD
Regular price Sale price $499.00 USD
Sale Sold out

Product Description
These inverter-duty, 3-phase gearmotors feature die-cast aluminum gearcases, and permanent heavy-duty gear oil lubrication. Gears feature hardened steel construction. Rotation: reversible.

  • Gearmotor Type: AC Gearmotor
  • Gearmotor Voltage:: 208-230/460V AC
  • Gearmotor Phase: 3
  • Torque: 341 in-lb
  • Gearmotor Shaft Type: Single
  • Gearmotor Shaft Orientation: Parallel
  • Gearmotor Rotation: CW/CCW
  • Nameplate RPM: 9 RPM
  • Gearmotor Enclosure: Totally Enclosed Fan-Cooled
  • Gearmotor Mounting Position: Horizontal or Vertical Shaft Down
  • Gearmotor Brake Type: None
  • Length Less Shaft: 11-9/20 in
  • Hz: 60 Hz
  • No Load RPM: 10 RPM
  • Overhung Load: 327 lb
  • Input HP: 1/6 hp
  • Gear Ratio: 7.500694444
  • Full Load Amps: 1.0/0.5
  • Insulation Class: F4
  • Thermal Protection: None
  • Ambient Temp.: 40 °C
  • Motor Type: 3-Phase
  • Shaft Dia. (Dimension U): 3/4 in
  • Shaft Length (Dimension V): 1.63 in
  • Keyway Size Type: 0.18 sq in x 1 in
  • Bearings: Gearbox: Heavy Duty; Needle Roller. Motor: Heavy Duty Ball
  • Lubrication: Permanent Heavy Duty Gear Oil
  • Finish: Black High Gloss Enamel
  • Housing: Rolled Steel
  • Gear Case Material: Die Cast Aluminum
  • Gears: AGMA Class 9; Precision Machined and Hardened
  • Gear Material: Precision Machined and Hardened
  • Gear Type: AGMA Class 9
  • Seals: Heavy Duty; Single Lip; Spring Loaded
  • Application: Inverter Duty
  • Standards: UL/CSA
  • UNSPSC: 20101617

*~ FREE US SHIPPING ~*
